Laser welding quality depends on the combined effects of the type of laser, workpiece material properties, material assembly, shielding gas, and environmental control. Optimizing quality means controlling penetration depth, minimizing the size of the heat-affected zone (HAZ), avoiding defects such as porosity and lack of fusion, and achieving consistent weld geometry. This guide organizes key factors, supplemented by experimental tables and comparisons, to assist engineers, technicians, and advanced enthusiasts in adjusting parameters and understanding trade-offs.

Selection of Materials and Lasers

The absorption characteristics of welding materials for lasers of different wavelengths and the geometry of the welding materials will affect absorption, heat distribution, and welding stability.

Laser Source Types (Fiber, Carbon Dioxide, YAG, Semiconductor)

The selection of laser light sources affects the beam quality factor (M²), wavelength, efficiency, and actual power range. The following is a comparison table.

Material Composition, Reflectance, and Thickness

High-reflectivity metals (copper, aluminum) pose challenges in absorption at common wavelengths—they reflect more incident rays and can quickly conduct heat away, thus requiring higher power, adjustment of focusing strategies, preheating, or adjustment of pulses. Thickness directly determines whether conduction welding or keyhole welding is applicable and determines the required power and welding speed.

The following is the welding parameter table (1200W, 850W, 700W test group). These data provide reference ranges for actual parameters when welding stainless steel, carbon steel, galvanized steel, and aluminum under different machine configurations.

The following welding data from Xlaserlab Laboratory is provided for users' reference.

Geometry and Assembly of Welding Materials

Joint type (butt, lap, corner), gap size, and clamping tolerance have a significant impact on heat flow and fusion. Even if the power and speed seem appropriate, poor assembly or excessive gaps can lead to lack of fusion defects. Precise clamping and fixtures should be used when welding small gaps; if gap compensation is required, filler wire can be considered.

Laser Processing Parameters

Laser processing parameters are the primary controlling factors used to set the weld geometry, depth, and stability. The most influential parameters include laser power, welding speed, focal position (light spot size/defocus amount), and, where applicable, pulse characteristics (frequency, pulse width, waveform).

Laser Power and Power Density

Laser power controls the energy entering the keyhole or molten pool. With fixed focus and travel speed, increasing the power causes the welding process to transition from conduction welding (shallow penetration, wide weld bead) to keyhole/deep penetration welding (high aspect ratio). In fact, there are threshold powers that define these modes; below the lower threshold, conduction welding occurs; above the upper threshold, stable deep penetration (keyhole) welding can be achieved. Between the two thresholds, instability may occur, with significant variations in depth/width. (In the figure, H represents conduction welding, U represents unstable welding, and P represents stable deep penetration welding)

Practical Tips: Increasing power can increase penetration depth, but if the power is too high at the selected speed/focus, beware of excessive vaporization, spatter, or unstable keyholes.

Focus Position, Light Spot Size, and Beam of Light Quality

Focus on the geometric shape and its impact on the light spot diameter and penetration depth

The focal position (△f) is the distance from the focal point to the surface of the workpiece. △f = 0 indicates that the focal point is exactly on the surface. A positive △f indicates that the focal point is above the surface material, while a negative △f indicates that the focal point is below the surface (inside the material). The focal point affects the size of the light spot, which in turn affects the power density (W/mm²).

Recommendation: For stainless steel and carbon steel, a positive focal length (focus above the surface) generally produces a deeper penetration depth; for highly reflective materials such as copper and aluminum, a slight negative focal length can be used to increase absorption and reduce back reflection.

Welding Speed

The welding speed data obtained using a 1000W fiber laser on a 5mm carbon steel base material, with Δf being -0.5mm.

Welding speed is inversely proportional to heat input. A faster speed reduces penetration depth and weld width; a slower speed increases heat input and penetration depth, but may cause burn-through in thin materials or excessive heat-affected zones in heat-sensitive components. (In the figure, H represents heat conduction welding, U represents unstable welding, and P represents stable deep penetration welding)

Pulse Characteristics (Applicable to Pulse Systems)

Pulsed lasers introduce important additional control parameters: pulse energy, frequency, and pulse width determine the overlap rate, peak power, and thermal cycle per pulse. Pulse waveform and timing affect spatter, surface finish, and keyhole initiation/closure. Continuous wave (CW) lasers and modulated continuous waves also require attention to waveform.

Protective Gas and Environmental Factors

Shielding Gas Selection and Flow Rate

Shielding gas can prevent the oxidation of molten metal and reduce the formation of plasma above the keyhole that may absorb laser energy. Common gases include: argon (an inert gas suitable for various metals), helium (with higher thermal conductivity, which helps with the keyhole stability of certain alloys), and nitrogen (reacts with certain steels and requires careful use). Gas flow rate and nozzle geometry are important. Insufficient flow rate can lead to oxidation; excessive flow rate may disrupt the molten pool or blow away the shielding gas.

Influence of Surface Cleanliness, Tooling Fixtures, and Operators

Dirt, oil, rust, or plating can reduce the absorption rate and may lead to porosity or inclusions. A strict cleaning procedure (degreasing, mild mechanical cleaning), consistent tooling fixtures, and experienced operator settings can significantly improve the yield. Machine maintenance - optical element cleanliness, power stability, and proper alignment - also affects quality.

Defects, Troubleshooting, and Quality Control

Common Defects and Their Causes

Porosity: Caused by contamination, gas entrapment, or unstable small holes. Remedial measures: Strengthen cleaning, adjust shielding gas, reduce welding speed, or adjust pulse parameters.

Spatter: Caused by excessive keyhole collapse or high power. Solution: Reduce peak energy or change pulse shape.

Incomplete fusion / lack of penetration: Low power or high speed; poor focusing. Solutions: Increase power, reduce speed, improve focusing, or reduce the gap.

Keyhole instability (oscillation): Usually caused by parameters being between the conduction and stable keyhole regions. Solution: Move to a stable power/speed region or adjust the focal position.

Crack: Material properties (such as certain steels); Remedy: preheat or use filler material and implement appropriate cooling control.

Monitoring and Process Optimization

Online monitoring (optical sensors, acoustic monitoring, photodiodes) and post-weld inspection (appearance, cross-section, X-ray for detecting hidden porosity) enable feedback and iterative adjustment. During adjustment, change one parameter at a time and record the results. Create parameter maps for each material and thickness to expedite production setup.

Practical Advice and Adjustment Checklist

Start with the baseline table:Use the reserved 1200W/850W/700W tables as the starting point for common materials.

Univariate Tuning: Adjust power, speed, or focus separately to identify sensitive areas.

Maintain optical components and cleanliness:Regularly clean optical components and pre-clean parts.

Use appropriate shielding and nozzle settings:Verify gas flow and nozzle geometry for each joint type.

Confirm fixture and clearance control: Maintain consistent assembly tolerances; if clearance dimensions are specified, use filler wire.

Recorded Results:Establish a parameter recipe library (material × thickness × laser model) to ensure repeatability.

Practice Run Quick Checklist:

1:Has the beam of light focusing (light spot size and △f) been verified?

2:Is the power stable and within the expected range?

3:Has the shielding gas type/flow rate been verified?

4:Has the part surface been properly cleaned and clamped?

5:Are the pulse settings (if in pulse mode) suitable for the reflectivity of the material?

Conclusion

The quality of laser welding depends on a balanced combination of laser selection, laser process parameters (power, speed, focus, pulse), material properties (absorptivity, thickness, composition), material geometry, and environmental control (protection, cleanliness, fixtures). The saved experimental data sheets and the comparison results among fiber lasers, CO2 lasers, and semiconductor lasers should serve as reliable initial references. For each new material and joint design, establish a small parameter matrix to determine stable and repeatable settings.



When using consumer-grade or compact multi-functional laser welding systems, select equipment with flexible power, focusing, and pulse adjustment capabilities and excellent beam quality (M² value close to 1.1 - 1.5). Such systems are more likely to replicate laboratory-level results in actual products.
