Semiconductor-based compact desktop laser welder — a powerful tool for thin-sheet welding.
Couldn't load pickup availability
Technical Specifications
Product Model
X1 Pro
X1
Laser Light Source
Fiber Laser
Semiconductor Laser
Average Laser Power
700 W
460 W
Power Supply Voltage
100~240V AC, 50/60Hz
100~240V AC, 50/60Hz
Cooling System
Air-Cooled
Air-Cooled
Cable Length
5 m
2 m
Photoelectric Conversion Rate
35%
50%
Power Consumption
2,800 W
2,500 W
Laser Wavelength
1,080±10 nm
900~1,000 nm
Welding Thickness
0.5~3 mm
0.2~2 mm
Welding Speed
0~120 mm/s
0~100 mm/s
Output Mode
Continuous Wave / Pulsed
Pulsed
Weight
19 kg (41.89 lb)
12 kg (26.45 lb)
Dimensions
470 x 205 x 335 mm18.5 x 8.07 x 13.19 in
395 x 189 x 265 mm 15.55 x 7.44 x 10.43 in
Working Temperature
-20°C (-4°F) ~40°C (104°F)
-20°C (-4°F) ~ 40°C (104°F)
Recommended Gases
Nitrogen / Argon
Nitrogen / Argon / Compressed Air
Recommended Welding Gas Flow
10~15 L/min
10~15 L/min
Recommended Cleaning Gas Flow
10~15 L/min
––
Recommended Cutting Gas Flow
15~20 L/min
––
Operating Gas Pressure
0.2~0.8 Mpa
0.2~0.4 Mpa
Gas Hose Outer Diameter
6 mm
4 mm
Materials
Stainless Steel
Carbon Steel
Iron
Galvanized Sheet
Aluminium
Brass
Copper
Zinc Alloy
And More
